High-Performance TUV-Certified PV Branch Connectors
Insulation material
PPO/PC
Rated Current
50A
Rated Voltage
1000V/1500V DC
Contact Resistance
<0.5mΩ
Waterproof Protection
IP68
Ambient temperature
-40℃-+120℃
Waterproof Protection
IP68
Flame Class
UL94-V0
Certification
IEC62852 /UL6703
PV Branch Connector
JZD Cable’s PV Branch Connectors are engineered for superior performance in solar energy systems, featuring full TUV certification (IEC 62852) compliance. These high-efficiency connectors enable secure parallel connections between photovoltaic modules, combiner boxes, and inverters.
Key Features:
✔ TUV Certified for Safety & Reliability
✔ IP68 Waterproof & UV-Resistant Housing
✔ 1000V/30A Maximum Rating
✔ -40°C to +85°C Operational Range
✔ Multi-Contact Plating for Optimal Conductivity
✔ Tool-Free Installation Design
Application
• Utility-scale solar farms
• Commercial rooftop PV systems
• Residential solar installations
• Solar street lighting projects
• Off-grid photovoltaic arrays
