Products Supplied:
- JZD THHN Building Wire (UL 83, Nylon-Jacketed, for conduit-based branch circuits)
- JZD NM-B Non-Metallic Sheathed Cable (UL 719, for concealed in-wall wiring)
Specifications & Quantities (Preliminary):
- THHN (Stranded Copper): 3.5mm² (12 AWG) — 2000m; 5.5mm² (10 AWG) — 1000m; 8.0mm² (8 AWG) — 3000 m; 14mm² (6 AWG) — 2000 m; 22mm² (4 AWG) — 1000m; 35mm² (2 AWG) — 1000m
- NM-B Cable: 12/2, 12/3, 10/2, 10/3 — 5000m each
Client: Manila-based cleanroom contractor / EPC firm]
Project Name: GMP Pharmaceutical Cleanroom Manufacturing Facility, Manila, Philippines
Project Commencement Date:2025
Project Details & Narrative:
Industry Context — Pharmaceutical Cleanrooms in the Philippines
The Philippines is rapidly emerging as a pharmaceutical manufacturing hub in Southeast Asia, driven by government initiatives to strengthen domestic drug production and attract foreign investment. Metro Manila, in particular, has seen a surge in GMP-compliant pharmaceutical facilities — including sterile injectables, oral solid dosage, and biologics production lines.
Pharmaceutical cleanrooms operate under the strictest environmental controls in any industry. GMP regulations mandate:
- ISO Class 5–8 cleanroom environments maintained 24/7
- Precise temperature (±1°C) and humidity (±5% RH) control
- Positive or negative pressure cascades between zones
- Continuous particulate monitoring with validated HVAC systems
- Comprehensive documentation trail for every installed component
Cable selection in this context is not trivial. Every material inside a pharmaceutical facility — including electrical cables — must meet stringent safety, cleanliness, and reliability standards. A single cable failure can trigger a batch rejection worth millions.
The Project
In 2024, a Manila-based cleanroom contractor was awarded the turnkey electrical package for a new pharmaceutical manufacturing facility in Metro Manila. The facility was designed to produce sterile injectables, requiring multiple ISO-classified cleanroom zones interconnected by pressurized gowning corridors and material airlocks.
The electrical scope covered:
- Cleanroom lighting and utility power circuits (THHN in EMT conduit, exposed in interstitial spaces)
- Office and administration wing wiring (NM-B for concealed in-wall runs, standard Philippine construction practice)
- HVAC equipment feeds — AHU and fan coil unit circuits (THHN, larger AWG, conduit-routed)
- Nurse call, intercom, and access control low-voltage backbones (NM-B multi-conductor)
- Gowning room and airlock power outlets (THHN in surface-mounted raceway)
Why THHN + NM-B?
This project called for two distinct wiring methods, reflecting the dual nature of a modern pharmaceutical facility:
THHN (Thermoplastic High Heat-resistant Nylon-coated) — for all conduit-based installations:
- Nylon jacket: Provides mechanical protection during conduit pulls — essential in cleanroom construction where conduit runs are long and complex
- 90°C dry / 75°C wet rating: Handles the heat load from densely packed conduit banks in interstitial spaces above cleanroom ceilings
- Gasoline & oil resistance: Critical for mechanical rooms housing standby generators and HVAC compressors
- UL 83 listed: Full compliance with Philippine Electrical Code requirements, which reference NEC standards
NM-B (Non-Metallic Sheathed Cable) — for concealed in-wall wiring in office and support areas:
- UL 719 listed: Recognized by Philippine construction practice for concealed residential and light commercial applications
- PVC outer jacket + paper separator: Provides insulation redundancy in concealed spaces
- 90°C rated conductors: Consistent thermal performance with THHN circuits
- Cost-effective: For office/admin areas where conduit is not mandated, NM-B offers significant material and labor savings
The Contractor’s Challenge
The cleanroom contractor faced a procurement dilemma: source THHN from one supplier and NM-B from another, each with separate logistics, minimum order quantities, and documentation streams — or find a single manufacturer who could supply both under one quality management system.
They chose the latter approach — and issued an RFQ to JZD Cable.
The Qualification Process
As a specialty cleanroom contractor with a portfolio of FDA-audited facilities, the client maintained an exceptionally rigorous supplier qualification process:
1.UL Documentation Verification: JZD submitted UL 83 file numbers (THHN), UL 719 file numbers (NM-B), UL follow-up service reports, and labeling samples — all cross-referenced by the contractor’s QA/QC team
2.Sample Procurement & Independent Testing: The contractor purchased random samples and sent them to a Philippine-accredited testing laboratory for:
- THHN: Conductor resistance (ASTM B3), insulation thickness, dielectric withstand, nylon jacket abrasion, heat resistance, cold bend
- NM-B: Jacket integrity, conductor insulation thickness, dielectric withstand, flame propagation (UL 1581 VW-1 equivalent)
JZD’s THHN and NM-B samples passed all tests with results ranking among the top tier.
3.Factory Quality Audit: The contractor conducted remote audit of JZD’s Shenzhen production facility, verifying:
- Raw copper procurement (99.95%+ purity certification)
- THHN nylon extrusion process consistency
- NM-B assembly line quality controls
- Batch traceability from raw material to finished reel
- ISO 9001 quality management system compliance
Color Coding Verification: The facility required specific color codes: black/red/blue for 3-phase circuits, white for neutral, green for ground, plus custom colors for emergency and life-safety circuits. JZD confirmed capability for all required colors on both THHN and NM-B.
How JZD Cable Won
After 3 months of qualification, JZD was selected over competitors based on:
- Dual Product Capability: JZD was the only supplier who could provide both UL-certified THHN and NM-B from a single factory — eliminating the need for the contractor to manage two supplier relationships, two sets of shipping documents, and two quality audits
- Superior Lab Test Results: JZD’s THHN samples demonstrated insulation thickness uniformity exceeding UL minimums by a comfortable margin — an indicator of production consistency that the contractor valued highly for a GMP-regulated project
- GMP Documentation Readiness: JZD provided full material traceability documentation — mill test reports, batch certificates, UL compliance certificates — in the format the contractor needed for their own GMP validation submission
- Competitive Landed Cost: FOB Shenzhen pricing on THHN combined with volume NM-B pricing, plus consolidated container shipping to Manila, delivered total landed cost savings of approximately [待确认 — %] vs. multi-supplier sourcing
- Responsive Technical Support: JZD’s engineering team answered detailed technical queries about nylon jacket formulation, NM-B jacketing compound, and flame-retardant properties within 24 hours — a responsiveness that impressed the contractor’s project manager
Delivery & Quality Assurance
Cables were manufactured in 8 weeks, with each shipment including:
- UL Certificate of Compliance with traceable file numbers
- Mill test reports for copper conductor (99.95%+ purity)
- Factory test data (conductor resistance, insulation resistance, hi-pot test results)
- Reel-by-reel packing list with serial number traceability
- NM-B cut-length labeling with sequential production coding
Shipments were consolidated into 2 × 40GP containers, shipped from Shenzhen to Manila Port, and cleared through customs within 30 days
Installation & Outcome
Post-installation feedback from the contractor:
- THHN pulled smoothly through EMT conduit with zero nylon jacket damage — the nylon coating’s lubricity reduced installation time by an estimated 15%
- NM-B cable installed efficiently in office/admin wall cavities — the sequential foot markings sped up cut-to-length work
- All circuits passed Philippine Electrical Code inspection on first attempt
- The cleanroom achieved its target ISO classification with all electrical systems fully validated
- Zero cable-related defects reported during commissioning or initial production runs
The cleanroom contractor has since listed JZD Cable as a preferred electrical cable supplier and initiated discussions for cable supply on two upcoming pharmaceutical projects in the Philippines.
JZD Cable Cleanroom Cable Solutions:
| Cable | Cleanroom Application | Key Specification | Certification |
|---|---|---|---|
| THHN | Cleanroom branch circuits (conduit), mechanical room feeders, airlock/gowning room power | Nylon jacket, 90°C dry rating, gasoline & oil resistant | UL 83 |
| NM-B | Concealed in-wall wiring for office/admin wings, low-voltage backbones, support areas | PVC jacket, 90°C conductors, paper separator | UL 719 |
